Heavy duty item palletizing and depalletizing robot automation system

It is a robot automation system that applies 3D-based sorting conveyors and palletizing/depalletizing technology to load heavy products.


It solves the problems of work difficulty and fatigue caused by repeated movements during heavy loading work, effectively maximizing productivity. Safety fences and light curtains are installed to eliminate work safety insensitivity and are designed to automatically stop when entering the robot area, providing a safe working environment for workers.



The introduction of automation increases work efficiency through new technology acquisition and data analysis.

Category Details
Main Application Field Automation Industry
Product Type Brils-A-00 / Palletizing and Depalletizing Automation System
Size and Weight 11090mm X 3140mm X 2370mm
Frame Structure High-Strength Aluminum Profile Structure
Utility 110~220 VAC, 1Ph, 50/60 Hz, 50A
Safety Configuration Safety PLC & Relay, Safety Fence & Light Curtain
